| 系統 | | 處理器 | 6th Generation Intel? Core? i7/i5/i3/Celeron Processor | | 芯片組 | integrated in Processor (SOC) | | 系統內存 | 1 x 260-pin DDR4 SODIMM (non ECC) support up to 16GB | | I/O 芯片 | EC IT8528E | | 看門狗定時器 | H/W Reset, 1sec. ~ 65535sec. and 1sec./step | | 硬件狀態監控 | Monitoring System Temperature & Voltage | | TPM | Infineon TPM 2.0 (SLB 9665 TT2.0) | | SBC | ARC-SKLU + Isolation IET board
(Default IET: ARC-SKLU DB-A I/O Ports -> Extend 1x USB / 1x COM / 1x LAN
Optional IET : ARC-SKLU DB-B I/O Ports -> Extend 2x USB 2.0 / 1x HDMI / 1x Line out / 1x Mic in)
| | 其他 | iAMT 11.0 support for i7/i5 CPU |
| 擴展 | | 擴展 | 1 x Full size mini PCIe slot (for mSATA & PCIe & USB2.0 signal) |
| 存儲 | | 存儲 | 1 x 2.5" Drive Bay |
| 面板規格 | | LCD尺寸 | 21.5" | | 顯示類型 | Full HD | | 分辨率 | 1920 x 1080 | | 像素間距 | 0.24795 (H) x 0.24795 (V) | | 亮度 | 250 cd/m2 | | 對比度 | 3000 | | 視角 | 89(U), 89(D), 89(L), 89(R) | | 響應時間 | 18ms | | 背光 | LED
| | 觸摸屏信息 | Projective Capacitive
| | 觸摸燈傳輸 | 86%
| | 觸摸控制器 | USB touch (EETI EXC3188)
|
| I/O | | USB Port | 4 x USB 3.0
2 x USB 2.0 (by pin header)
1 x Isolation 5-kV USB1.1 (by IET module) | | SATA | 1 x SATA III | | 串口 | 1 x RS-232/422/485
1 x RS-232
1 x Isolation 5-kV RS-232/422/485 (by IET Module) | | 其他 | Dual LED Reading Light Bar
I/O Cover
Optional MSR/SCR Module with MOQ apply
Optional Smart Backup Battery Module
Optional WIFI/BT module (by mini PCIe)
Optional Handset & 1D Barcode Scanner |
| 顯示 | | 芯片組 | Intel? HD Graphics 520 | | 分辨率 | HDMI: 3840 x 2160 @ 24Hz (optional by IET module) |
| 音頻 | | 芯片組 | Realtek ALC888S | | 揚聲器輸出 | 2 x 2W |
| 以太網 | | 芯片組 | 1 x Intel? I211AT, 1 x Intel? I219LM
1 x Isolation 5-kV Intel? I210AT (by IET Module) | | 以太網接口 | 10/100/1000 Base-Tx GbE compatible | | 網絡接口 | 2 x RJ-45
1 x RJ-45 (by IET module) |
| 電源 | | 電源連接器 | Lockable DC Jack, +12V~+26V | | 電源模式 | AT/ATX (ATX is default setting) | | 電池工作時間 | max. 20 mins backup operation | | 電池 | 1100mAh 4S1P (by optional) | | 適配器 | Medical grade
Input: 100~240 Vac/50~60Hz;
Output: 90W Adapter (19V/4.74A Adapter) |
| 機構 & 使用環境 | | 操作溫度 | 0°C ~ 40°C (32°F ~ 104°F) | | 存儲溫度 | -30°C ~ 70°C (-22°F ~ 158°F) | | 工作濕度 | 0% ~ 90% Relative Humidity, Non-condensing | | 尺寸 (寬 x 長 x 高) | 539.6 x 342.6 x 45.2 mm | | 防護等級 | Front IP65 | | 振動試驗 | With SSD/mSATA : 1.5Grms, IEC 60068-2-64, Random, 5 ~ 500Hz, 30min/axis | | 沖擊試驗 | With CF/SSD : 10Grms, IEC 60068-2-27, Half Sine, 11ms | | 系統風扇 | Fanless | | 結構-前部 | White Plastic | | 結構 - 后部 | White Plastic | | Finishing | Anti-Microbial | | Fanless | Yes | | 顏色 | White | | 重量 | 6.3 Kgs |
| 認證 | | 認證 | CE :
IEC/EN60601-1-2
FCC :
Part 15 Class B
UL60601-1:
AAMI /ANSI ES60601-1:2005/(R)2012 and A1:2012,C1:2009/(R)2012 and A2:2010/(R)2012
CB:
IEC 60601-1/A1:2012 & EN 60601-1/A1:2013 (Ed 3.1)
EN 60601-1:2006+A11:2011+A1:2013+A12:2014
|
| 軟件支持 | | 軟件支持 | Win 7, 8.1, 10, Linux |
|
|
